MPPS V21 MAIN TRICORE MULTIBOOT with Breakout Tricore Cable Support Checksum and ECU Recovery Function

Item No.UKSE134
4.7 stars, 13 reviews.
In Stock
Retail price:€99.99
Buy it Now (1 pcs):€85.00 You save €14.99
Size/Spec.:
simple airmail post service no tax
Quantity:

Summer New Arrivals & Bundle Sales: Spend Less and Save More
http://www.cartool.co.uk/producttags/2017-new-arrival.html

Fast Shipping and Cost-Effective
Ship from UK No Tax: Direct Ship to UK and European Countries
http://www.cartool.co.uk/producttags/ship-from-uk.html
Shipping:
Free Shipping   Standard Flat Rate Shipping Service
Estimated delivery time: 7-15 working days.See details»
Weight:
100g
Returns:
Return for refund within 7 days,buyer pays return shipping.Read details »
Share |
Any Questions? Get Technical Service.
Buy more related products and get nice price!
MPPS V16.1.02 ECU Chiptuning for EDC15 EDC16 VAG EDC17 CHECKSUM Read And Write Memory
Newest MPPS V16.1.02 is professional ecu chip tuning tool, it is completely working through obd2 port, no need soldering or connecting cables, easy and high efficiency.    More Details »
Retail price: €79.00 Buy it Now (1 pcs): €18.99  76%  You save €60.01 Free Shipping
Size/Spec.: Netherland post no tax 7-15 working days
Quantity:
Add to Cart
MPPS V21 module adds support for advanced functions on Marelli ECU’s. MPPS covers a range of controllers including M3.8, M5.9, ME7xx, MED9, MED17, EDC15/16/17, Delphi, Siemens, Marelli, Delco, Sagem, Trionic and many others
MPPS V21 MAIN + TRICORE + MULTIBOOT with Breakout Tricore Cable

This module adds support for advanced functions on Marelli ECU’s.
MPPS covers a range of controllers including M3.8, M5.9, ME7xx, MED9, MED17, EDC15/16/17, Delphi, Siemens, Marelli, Delco, Sagem, Trionic and many others.

Software version: V21
Hardware version: V1.09.03

Warranty: one year
Support Multi-language:

mpps-v18-language-1mpps-v18-language-2
mpps-v18-language-3mpps-v18-language-4


MPPS V21 Install Tips:

1. Supports Win7 system only
2. Make sure install the mpps v21 software driver successfully before open the software.
3. Don't try to use other versions (mpps software or hardware) with our MPPS V21.

MPPS V21 New Features:

Read / Write of Micro, Flash and EEprom without using a BDM programmer!
Fiat 6F3 – Full Read / Write Micro, Flash and EEprom over K-line and CAN.
Fiat 6JF – Full Read / Write Micro and EEprom over K-line.
Fiat 8DF – Full Read / Write Micro and EEprom over K-line.
Fiat 8F2 – Full Read / Write Micro and EEprom over K-line and CAN.
Fiat 8F3 – Full Read / Write Micro and EEprom over K-line and CAN.
Fiat 8GM – Full Read / Write Micro and EEprom over CAN.
Fiat 8GS – Full Read / Write Micro and EEprom over CAN.
Fiat 5SF3 – Full Read / Write Flash and EEprom over CAN.
Fiat 5SF3 – Full Read / Write EEprom over K-Line.
Fiat 5SF8 – Full Read / Write Flash and EEprom over K-line and CAN.
Fiat 5SF9 – Full Read / Write Flash and EEprom over CAN.
Fiat ME7.9.10 – Full Read / Write Micro over CAN.
Fiat ME7.6.3 – Full Read / Write Micro over CAN.
Opel 6O2 – Full Read / Write Micro, Flash and EEprom over K-line and CAN.
Opel 6O3 – Full Read / Write Micro, Flash and EEprom over K-line and CAN.
Opel 6JO – Full Read / Write Micro and EEprom over K-line.

MPPS V21 Features:
This module adds boot mode support for controllers with the tricore processor.

Auto detects ECU and processor type. No need to select from list, everything is automatic!
Read/Write of all memories Eeprom, Irom, Xrom (where possible)
Patch function for OBD Flashing of TPROT ECU’s (supports only VAG at the moment)
TPROT / DS check feature, for testing if TPROT is active without opening ECU.
Supports Bosch upto TP12
Supports Siemens (current only for ECU’s without password protection),
Support for unlocking of VAG Simos PCR and Simos 8.
Checksum Correction supported for Bosch MEDC17.

The MPPS ECU chip tuning cable is a powerful programming tool. It offers general reading / writing operations and checksum support.

However it also includes some additional features:

Excellent recovery functions. In some cases MPPS can recover ECU’s which others tools can not even make communications with.
On certain controllers it even works when with no program is present (a blank memory).
Selectable full / partial reading and writing when the ECU allows this function.
Selectable reading / writing speed.
Writing “changes only” function for faster programming (when supported by the ECU).
Auto detection of K-Line/CAN, and option to bypass and force preferred means of communication.
Temporary bypass of immobiliser to allow flashing on the bench on ME7 systems.
Boot mode support for ECU’s with C167 and ST10 processors.
EEprom read/write functions for some ECU’s are included.
VAG MEDC17 TPROT level checking without opening the ECU.

MPPS V21 Software Display:

MPPS V18 MAIN + TRICORE + MULTIBOOT with Breakout Tricore Cable Software

mppsv18-se134








Package includes:

1pc x MPPS V21
1pc x Breakout Tricore cable
1pc x CD Software


MPPS V21 PCB Board Display:

mpps-v18-pcb-board-display

mpps-v18-main-tricore-multiboot-cable-pcb
mpps-v18-main-tricore-multiboot-cable-pcb-002


MPPS V21 FAQs:

Q:What is the meaning of ”TRICORE + MULTIBOOT” for MPPS v21?
A:That means a way to dissemble the ecu, weld the boot chip point, and use ecu adapter definition to read ECU data.
MPPS V21 supports Tricore, MultiBoot, OBD.

Q: What is the meaning of ”breakout” among MPPS v21 Breakout Tricore Cable?
A:It is the connector adapter.

Q: Can Mpps v21 support C167 and ST10?
A: Yes, Boot mode support for ECU’s with C167 and ST10 processors.

Q: MPPS V21 can auto detect K-Line?
A: Yes, it support auto detection of K-Line/CAN.

Q: What about MEDC17 TPROT level checking through mpps?
A: VAG MEDC17 TPROT level checking without opening the ECU.

Q: Any option to bypass?
A: MPPS V21 has option to bypass and force preferred means of communication; temporary bypass of immobiliser on ME7 system.

Q: MPPS V21 for eeprom r/w?
A: Yes, EEprom read/write functions for some ECU.

Q: Can Mpps v21 support immo off without welding the boot chip?
A: MPPS v21 doesn’t support immo off. And Mpps v21 conenct to the vehicle with obd2 port, no need welding.

Q: Can Mpps v21 read PSG16?
A: Check MPPS V21_Carlist

Q:Can MPPS v21 be connected with internet?
A:You’d better not.

Q:Kess v2 vs MPPS v21
A:Kess v2 is better, more features and possibilities. but mpps v16 is working very stable for a kess do PCR 2.1
