Product Description
- MaxiSys MS906TS Wireless TPMS & Advanced Diagnostics System
- Operating on the Android navigation system, the MS906TS provides amazingly fast sensor programming and diagnostic scan functions with its powerful running speed and large 32 GB solid state hard drive. The system also features the latest AutoVIN technology to identify vehicles in one touch as well as its exclusive AutoScan function. These features allow you to easily acquire vehicle information, scan all ECUs and run diagnostics on selected systems.
[Mega Sale] Autel MaxiSys MS906TS Wireless TPMS Advanced Diagnostics System
MaxiSys MS906TS Highlights:
1. One Year Free Update Online. After One Year,
Autel MS906TS Software Subscription Cost 859USD/ Year
2. Global Version, NO IP Restriction. You Can Do Software Downloads and Updates Online Without Limitation
3. Efficiently Provides Comprehensive Vehicle Diagnostics and Analysis Along with Universal TPMS Solutions
4. Wide Vehicle Coverage: It is compatible with most of the domestic, Asian and European vehicles, 1996 and newer.
5. Multi-Languages Supported: English, German, Spanish, French, Polish, Italian, Japanese, Korean, Dutch, Portuguese, Swedish, Russian
6. MS906TS is An All-in-One Industry First Combining Advanced Diagnostics with Complete TPMS Functionality, No Need Another TPMS Tool to Trigger, Relearn, or Program Autel MX-Sensors
New Added Functions
1. Guided Functions: Guide mechanics to repair vehicles one by one for Audi VW Skoda Jetta, Bently.
2. Battery Test (Work with Autel BT506): With bt506, you can perform full battery detect: battery register, battery reset, In/out vehicle test, etc.
3. Compatible with MaxiVideo MV108 Inspection Camera: Connect with MV108 borescope to enable up-close visual inspections in confined areas, such as engine cylinders
4. Autel Cloud Reports: Allowing uploading diagnostic reports to Autel Cloud and sharing to customers via QR Code/ email/ text message.
5. FCA Auto Auth to Connect FCA Server and Get Authorized to Diagnose Your Vehicles: for Chrysler, JEEP, Dodge, Fiat etc.(FCA after 2018). ONLY CAN BE USED IN USA CANADA MEXICO
Notes:
1. Doesn't Support Mileage Correction.
2. The Key Fob Programming is Not Supported As Well. If you need IMMO function, please check Autel Key Programming Tool.
MaxiSys MS906TS is the latest addition to the MaxiSys product line of advanced wireless diagnostic devices integrated with the TPMS antenna module. The device is based on the Android operating system featured with the best possible coverage of OE-level diagnostics and TPMS integration. Utilizing the powerful Exynos 5260 6-core processor (1.3 GHz quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15), an 8” capacitive HD touch screen, and long-distance wireless communication, the MaxiSys MS906TS efficiently provides comprehensive vehicle diagnostics and analysis along with universal TPMS solutions.
Product Features:
Extraordinarily powerful Samsung Exynos Hexa-core processor,
8.0” 1024x768 LED-backlit glossy Multi-Touch capacitive display with IPS technology for ultra-mobility,
Internal reliable 32GB SSD for better performance,
Built-in 8-megapixel rear camera with autofocus and flashlight,
Integrated TPMS antenna module for performing comprehensive TPMS service,
802.11b/g/n Wi-Fi to access your favorite web resources,
Unique ergonomic design with rubberized outer protection and a rugged internal housing,
Built-in rechargeable lithium-polymer battery for up to 14 hours of continuous operation,
USB, audio and auxiliary ports make it easy to connect accessories,
Open source Android Operating System for fast boot-up and multitasking,
Easy and intuitive navigation makes finding what you need simple and fast
The most extensive complete system coverage for more than 80 US, Asian and European makes and models
Exceptional OE-Level functionality from comprehensive OBDII diagnostics & services to advanced ECU coding
Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, coding etc.
Smart AutoVIN technology for identifying vehicle easily
Uniquely integrated TPMS service application designed for triggering known OEM TPMS sensors, programming Autel MX-Sensor and performing TPMS sensor relearn procedure
Automatic system and software updates with real-time push message notifications via internet
Instant remote control tech support anytime, anywhere
Cloud-based MaxiFix online community provides a vast database of diagnostic and repair tips and proven filed fixes
Interactive Data Logging sessions enable direct contact with Autel Technical Support for first-hand troubleshooting of diagnostic bugs and errors
One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organized
Enhanced wireless connectivity between the display tablet and VCI device allows greater mobility and ease at work
Convenient data management system for managing internal program applications and reviewing data
Highlights of Autel Maxisys MS906TS
【Upgraded Version of MS906BT / MP808TS】: Autel MS906TS diagnostic scanner, as one of the most professional diagnostic tools of MaxiSys line, is the combination of MS906BT and TS601. It is loaded with all TPMS functions to activate all known OEM TPMS sensors, view sensor data, program Autel MX-Sensors, and perform TPMS relearn and diagnostics.
【 ECU Coding for 80+ Vehicle Brands】: The Autel scanner advanced ECU Coding technology allows reprogramming adaptive data after repair or replacement to improve vehicle performance for 80+ brands of vehicles such as Toyota, Honda, Nissan, etc. ECU online coding and custom configurations are designed to unleash the hidden functions for Audi, VW, Skoda, Porsche, etc., such as personalization, guided function, modifications.
【OE-Level Full-System Diagnosis & 33+ Special Functions】: OE-Level Full-System Diagnosis & 33+ Special Functions: Professional as Autel is, the MS906TS scans all systems of the vehicle faster, including engine, transmission, ABS, etc. and presents more accurate reports; 33+ services, including Oil Reset, IMMO Keys (disable lost keys, add new keys), ABS Bleeding, Injector Coding, etc., make maintenance more efficient and convenient.
【 Bi-directional Control】: The active test enables the automotive scan tool to perform specific tests and functions to check the vehicle operating system, such as turning the fuel pump on and off, cycling the a/c clutch on and off, and performing evaporation emission leak tests. Bidirectional control is to troubleshoot quickly and solve problems promptly.
Functions:
1. Full Systems Diagnoses In All Vehicle Systems
Autel MS906TS can access to ALL vehicle systems and subsystems, such as Body, Chassis, Powertrain, Network and etc., to perform a comprehensive scanning on ECUs to locate fault systems and retrieve DTCs.
1). To diagnose Brake System if you feel the brake pedal is mushy and notice unusual odor or noise, etc. A properly operating brake system is critical to ensure safe vehicle control and operation;
2). To diagnose Emission System if the system is affected by vehicle age or poor quality fuel. A good emission system reduces harmful gases to a large degree and protects you from being fined;
3). To diagnose Fuel system if vehicle won't start or "Check Engine" light is illuminated. Check car's fuel system regularly ensures the best performance of your car with the lowest emissions;
4). To diagnose Transmission if your car is slipping or difficult to shift. The system plays an important part in the overall performance of your car;
5). To diagnose Wiper System if you observe chattering or streaking wiper. If the car is not regularly checked, the accident might happen because you can’t see clearly;
6). To diagnose Light System if you see rapid signal blinking or dimming lights. And many more ...
2. Complete TPMS Services
includes but not limited to Sensor Activation, Sensor Relearn, Sensor Programming, TPMS diagnose, Read/clear TPMS DTCs, Read Sensor ID etc.
1) TPMS Sensor Activation: MS906TS is capable of activating 99% of all known TPMS sensors, which is significant for ensuring that the new TPMS sensor is in proper working condition.
2)TPMS Sensor Relearn: MS906TS can write the TPMS sensor IDs to the TPMS module.
3) TPMS Sensor Programming: Autel MS906TS just program Autel MX-sensor.
* Copy by Activation: This function is used to activate or trigger the original sensor and retrieve the ID of the sensor, and then write the original sensor ID into the new MX-Sensor.
* Copy by OBD: Copy the sensor ID from ECU into a MX-Sensor.
* Copy by Input: The Copy by Input programming method uses the ID of the original sensor that is already stored within the TPMS ECU and therefore does not require the sensor be relearned if the new programmed sensor has been put in the same wheel location.
* Auto Create: This function is used to auto create unique ID(s) to 1-16 MX-Sensor(s). A random ID will be created for the MX-Sensor. This new ID differs from the ID stored in the TPMS ECU, therefore the sensor will have to be Relearned to the TPMS ECU.
4) TPMS Onscreen Relearn Procedures: This TPMS relearn tool can provide relearn procedures for specific sensors, to help quickly relearn the TPMS sensor with the following methods: Auto Relearn/ OBDII Relearn/ Stationary Relearn
3. Advanced ECU Coding
The Autel MS906TS professional auto scanner features advanced ECU coding, which allows you to establish a data connection to the vehicle' s electronic control unit via a VCI for vehicle diagnosis, repairs, or coding. It is mainly used for ECU recognition after module replacement and for ECU modification to reveal hidden features. Also equipped with ECU online coding and customized configurations for high-end models.
1) Support online coding and personalization for BMW, like Power Mirrors; Enable/disable auto start-stop feature; Activate horn when locking vehicle…;
2) Support online coding, guided function, modifications for Volkswagen;
3) Support ECU coding, ECU online coding, and guided function of providing repair tips after reading DTCs for Porsche, simply follow the device interface prompts to complete matching, calibration, and troubleshooting, such as SAS reset, suspension matching, headlight calibration…;
4) Support ECU online coding for Renault;
5) Support customized configuration for Toyota, Nissan, Peugeot, and more
4. Services Functions
Doing regular and routine maintenance on a modern car is impossible without a diagnostic system. Even the simplest procedures require the participation of an auto scanner. That's why Autel engineers have been working on them and making them as user-friendly as possible in the new MaxiSys MS906BT. Now you can easily do functions like:
Oil Reset: Reset the oil change calculator in the engine and automatic transmission
EPB: Replacement of brake pads on vehicles with an electric parking brake
SAS: Adaptation of the sensor to the angular position of the steering wheel
DPF: Regeneration of diesel particulate filter
Brake Bleed: ABS Brake Bleeding
IMMO: Immobilizer keys functions(All keys lost, add new keys)
BMS: Battery registration and reset
Seats, Injector, CHG tire size, TEC Learn, Suspension, Throttle, WIN OR ROOF, Lang Change, Headlamp.
Autel Maxisys Tablet Comparison
|
MaxiSys Elite
|
MaxiSys CV
|
MS908S Pro
|
MS908S
|
MS906TS
|
MS906BT
|
MS906
|
Function |
|
|
|
|
|
|
|
All Systems DTC Scan |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Service Function |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Bi-Directional Control |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Auto VIN Technology |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
ECU Coding |
√ |
-- |
√ |
√ |
√ |
√ |
-- |
ECU Programming |
√ |
-- |
√ |
-- |
-- |
-- |
-- |
MaxiFix Cloud-Based Info System
|
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Data Manager |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Shop Manager |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Remote Support |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Pre-scan Report & Post-scan Report |
North America Only |
-- |
North America Only |
North America Only |
√ |
North America Only |
North America Only |
Print Feature |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Multi-language Support |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Coverage |
|
|
|
|
|
|
|
Domestic/Asian/European Coverage(1996-Present) |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Hardware |
|
|
|
|
|
|
|
Display Size |
9.7" |
9.7" |
9.7" |
9.7" |
8" |
8" |
8" |
Wireless VCI |
MaxiFlash Elite |
MaxiFlash Elite |
MaxiFlash Elite |
Wireless Diagnostic
Interface |
MaxiVCI V100 |
MaxiVCI V100 |
-- |
Battery Life |
15400 mAh 3.7 V |
11000 mAh 3.7 V |
11000 mAh 3.7 V |
11000 mAh 3.7 V |
10000 mAh 3.7 V |
10000 mAh 3.7 V |
5000 mAh 3.7 V |
Memory Storage |
64GB |
64GB |
64GB |
64GB |
32GB |
32GB |
32GB |
Connector Kit |
√ |
√ |
√ |
√ |
√ |
√ |
√ |
Options |
|
|
|
|
|
|
|
TPMS |
-- |
-- |
-- |
-- |
√ |
-- |
-- |
Oscilloscope |
√ |
√ |
√ |
√ |
√ |
√ |
-- |
Inspection Camera |
√ |
√ |
√ |
√ |
√ |
√ |
-- |
ADAS |
√ |
-- |
√ |
√ |
-- |
√ |
√ |
Product Specifications:
Operating System: Android™ 4.4.2, KitKat
Processor: Samsung Exynos T5260 hex-core Processor (1.3 GHz quad-core ARM Cortex-A7 + 1.7 GHz dual-core ARM Cortex-A15)
Memory: 2GB RAM & 32GB ROM
Display: 8.0” LED capacitive touchscreen with 1024 x 768P resolution
Connectivity: Wi-Fi (802.11 b/g/n), USB: 2.0, Mini USB 2.0, Wireless BT V2.1+EDR, Class1, HDMI 1.4a, SD Card (support up to 32GB)
Camera (rear): Rear-facing, 8.0 Megapixel, AF with Flashlight
Sensors: Gravity Accelerometer, Ambient Light Sensor (ALS)
Audio Input/Output: Microphone, Single Speaker, 3-Band 3.5 mm stereo/standard headset jack
Power and Battery: 10,000 mAh 3.7 V lithium-polymer battery, Charging via 12 V AC/DC power supply
Input Voltage:12 V (9-35 V)
Power Consumption: 5 W
Operating Temperature: -10 to 55°C (14 to 131°F)
Storage Temperature: -20 to 70°C (-4 to 158°F)
Housing: Rugged housing and extra rubberized protection
Dimensions(W x H x D): 270.8 mm (10.0”) x 176.0 mm (6.9”) x 36.0 mm (1.4”)
Weight: NW: 1.10 kg (2.42 lb.)
Warranty: 1 year
Software Update: 1 year free
Package Includes:
1pc x Autel MaxiSYS MS906TS Main Unit
1pc x MaxiVCI V100
1pc x USB cable
1pc x Power adaptor
1pc x Cigarette lighte
1pc x Light fuse
1pc x Honda-3
1pc x Nissan-14
1pc x Mitsubishi-Hyundai-12+16
1pc x Kia-20
1pc x Benz-38
1pc x BMW-20
1pc x VW-AUDI-2+2
1pc x Fiat-3
1pc x PSA-2
1pc x GM-Daewoo-12
1pc x Benz-14
1pc x Chrysler-16
1pc x Quick-reference-guid
1pc x Packing-list
1pc x CD
1pc x Soft-cloth
1pc x Carry case
1pc x User manual
----------------------------------------------------------------------------------------------------------------------------------------
